Product Overview
Vibro Acoustics CM-2N-500, 2" (50 mm) Deflection CM Closed Mount Spring Isolators, 500 lbs rated load, Yellow, 2.153 inch deflection at rated load, 9.7 lbs isolator weight. Laterally supported, housed spring type isolator with telescoping equipment support plate, leveling bolt and hold-down nut for attaching equipment.
Springs are supported with a cup on a metal base plate complete with a ribbed neoprene vibration isolation pad, 1/4" (6 mm) thick, bonded to the base plate.
Steel telescoping housing incorporates neoprene stabilzers that prevent metal-to-metal contact while resisting movement and provides vertical damping.
Minimum 50% additional travel to solid
Minimum kx/ky ratio of 0.8
Springs are supported with a cup on a metal base plate complete with a ribbed neoprene vibration isolation pad, 1/4" (6 mm) thick, bonded to the base plate.
Steel telescoping housing incorporates neoprene stabilzers that prevent metal-to-metal contact while resisting movement and provides vertical damping.
Minimum 50% additional travel to solid
Minimum kx/ky ratio of 0.8
