Dwyer Instruments: Series LFM, Polycarbonate Flowmeter

Chemically Resistant, In-Line or Panel Mount Options, Adjustable Set Point Indicator Option

The SERIES LFM Polycarbonate Flowmeters are made of precision, injection molded polycarbonate bodies and fittings. This series consists of LFMA, LFMB, LFMC, LFMD, LFME and LFMF flowmeters with 3" (76 mm), 6" (152 mm), 5" (127 mm), 6" (152 mm), 8" (203 mm) and 11" (279 mm) respective scales. They feature dual, direct reading scales measuring in both GPM and LPM.

CAUTION: Series LFM Flowmeters are for indoor use only or areas without direct sunlight. Polycarbonate is adversely affected by ultraviolet light.

SERIES LFM Applications

  • Chill water flow
  • Reverse osmosis systems
  • Deionized water systems
